Data sheet?
| Shaft outer diameter | ?2mm |
|---|
| Max. response frequency | 100kHz |
|---|
| Max. allowable revolution | 6000rpm |
|---|
| Starting torque | Max. 5gf.cm(max. 0.00049N.m) |
|---|
| Resolution | 100P/R |
|---|
| Output phase | A, B, Z |
|---|
| Control output | NPN open collector |
|---|
| Power supply | 12VDC  ?5%(ripple P-P: max. 5%) |
|---|
| Connection type | Axial cable type |
|---|
| Protection structure | IP50 |
|---|
| Approval |  |
|---|
| Environment_Ambient temperature | -10 to 70?? storage: -20 to 80??/td> |
|---|
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
|---|
| Accessories | ?2mm coupling |
|---|
| Weight | Approx. 35g |
|---|
??ake sure that max. response revolution should be lower than or equal to max. allowable revolution when selecting the resolution.
[Max. response revolution (rpm) = Max. response frequency/Resolution ? 60sec]
??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated at no freezing or condensation.
