| Max. response frequency | 180kHz |
|---|---|
| Max. allowable revolution | 5000rpm |
| Output phase | A, B |
| Wheel diameter | 228.6mm(0.25yd) |
| Gear ratio | 4:1 |
| Number of pulses | 1 |
| Min. measurement unit | 1yd |
| Control output | Voltage |
| Power supply | 5VDC @(=) ?5%(ripple P-P: max. 5%) |
| Connection type | Axial cable type |
| Protection structure | IP50 |
| Approval | @(CE) |
| Environment_Ambient temperature | -10 to 70?? storage: -25 to 85??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Weight | Approx. 494g |
| Rotary Encoder | |
| Type | Incremental |
| Shaft type | Wheel |
| Output phase | A,B |
| Control output | Voltage output |
| Power supply | 5VDC andaring;andplusmn;5% |
| Wheel Circumference | 0.25 yd |
| Connector type | Cable |
| Min. Measuring Unit | 1 yd |
