Data sheet?
| Display method | 8-digit 7-segment LCD |
|---|---|
| Operation method | Count up, Count down, Count up/down |
| Terminal | Terminal block |
| Power supply | Built-in battery(over 7 years) |
| Input Method_Signal | No-voltage input(NPN) |
| Input Method_Reset | No-voltage input(NPN) |
| Max. Counting Speed | 1, 30, 1k [cps] |
| Min. signal Width | 20ms |
| Control output | Indicator |
| Protection structure | IP66(front panel) |
| Approval |   |
| Accessories | Mounting bracket, Rubber waterproof ring |
| Environment_Ambient temperature | -10 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 96g (approx. 50g) |
??xternal setting switch: SW1 is the front panel RESET key enable/disable setting switch.
??xternal setting switch: SW2 is the max. counting speed setting switch.
??xternal setting switch: SW3 is the decimal point setting switch.
??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated at no freezing or condensation.
