| Display method | 4-digit 7-segment LED |
|---|---|
| Operation method | Count up, Count down |
| Terminal | 8-pin plug |
| Power supply | 100-240VAC~ 50/60Hz |
| External Power Supply | Max. 12VDC @(=) ?10% 50mA |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Max. Counting Speed | 1, 30, 2k, 5k [cps] |
| Min. signal Width | 20ms |
| Control output_Type | 1-stage preset |
| Control output_Relay | SPST (1a): 1 |
| Protection structure | IP20(front panel) |
| Approval | @(CE) @(CULUS) |
| Environment_Ambient temperature | -10 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 130g (approx. 90g) |
