| Operation method | Time setting |
| Output Operation | SIGNAL ON DELAY, SIGNAL OFF DELAY, SIGNAL ON-OFF DELAY, FLICKER, INTERVAL |
| Time operation | SIGNAL ON START |
| Terminal | 11-pin plug |
| Power supply | 100-240VAC~50/60Hz, 24-240VDC @(=) |
| Setting range | 0.1 to 1 sec, 1 to 10 sec, 0.1 to 1 min, 1 to 10 min, 0.1 to 1 hour, 1 to 10 hour |
| Signal Input Method | No-voltage input(NPN) |
| Control output | Time-limit SPDT (1c): 2 |
| Approval | @(CE) @(CULUS) |
| Min. signal Width | START, INHIBIT, RESET: [No-voltage input] - Short-circuit impedance: Max. 1k?,Residual voltage: Max. 0.5V, Open-circuit impedance: Min. 100k? |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH |
| Weight | Approx. 95g (approx. 70g) |
