Data sheet?
| Display method | 3-digit 7-segment LCD |
|---|---|
| Operation method | Count up, Count down |
| Output Operation | ON DELAY, INTERVAL DELAY, FLICKER, ONE-SHOT OUT FLICKER, ON-OFF DELAY, OFF DELAY, INTEGRATION TIME |
| Time operation | SIGNAL ON START |
| Terminal | 8-pin plug |
| Power supply | 24-240VAC~, 24-240VDC  |
| Setting range | 0.01 sec to 9.99 sec, 0.1 sec to 99.9 sec, 1 sec to 999 sec, 0.1 min to 99.9 min, 1 min to 999 min, 0.1 hour to 99.9 hour, 1 hour to 999 hour, 10 hour to 9990 hour, 0 min 01 sec to 9 min 59 sec, 0 hour 01 min to 9 hour 59 min |
| Signal Input Method | No-voltage input(NPN) |
| Control output_Relay | Time-limit SPDT (1c): 1 |
| Approval |   |
| Min. signal Width_START | Approx. 20ms |
| Min. signal Width_INHIBIT | Approx. 20ms |
| Min. signal Width_RESET | Approx. 20ms |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH |
| Weight | Approx. 100g |
??ockets (PG-08, PS-08(N), PS-M8) are sold separately.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation environment.
??he weight includes packaging. The weight in parenthesis is for unit only.
Tags: Timer, Digital, 1/16 DIN, 10 Mode, Multi-Range, SPDT Out, 24-240 VAC/DC (socket required)
