| Display method | 4-digit 7-segment LED |
|---|---|
| Operation method | Count up, Count down |
| Output Operation | POWER ON DELAY, FLICKER |
| Time operation | POWER ON START |
| Terminal | 8-pin plug |
| Power supply | 100-240VAC~ 50/60Hz |
| External Power Supply | Max. 12VDC @(=) ?10% 50mA |
| Memory Protection | Approx. 10 years |
| Setting range | 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 99 hour 59 min, 0.1 hour to 999.9 hour, 1 hour to 9999 hour |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Control output_Type | 1-stage preset |
| Control output_Relay | SPDT (1c): 1 |
| Protection structure | IP20(front panel) |
| Approval | @(CE) @(CULUS) |
| Min. signal Width | RESET, INHIBIT: approx. 20ms |
| Environment_Ambient temperature | -10 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH |
| Weight | Approx. 130g (approx. 90g) |
