| Operation method | Time setting |
|---|---|
| Output Operation | FLICKER |
| Time operation | POWER ON START |
| Terminal | 11-pin plug |
| Power supply | 24VAC~ 50/60Hz, 24VDC @(=) |
| Setting range | 0.3 to 3 sec, 3 to 30 sec, 0.3 to 3 min, 3 to 30 min, 0.3 to 3 hour, 3 to 30 hour |
| Control output | Time-limit SPDT (1c): 2 or Instantaneous SPDT (1c): 1 + Time-limit SPDT (1c): 1 depending on output operation mode |
| Approval | @(CE) @(CULUS) |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH |
| Weight | Approx. 100g (approx. 75g) |
