| Operation method | Time setting |
|---|---|
| Output Operation | POWER OFF DELAY |
| Time operation | POWER OFF START |
| Terminal | 8-pin plug |
| Power supply | 100-120VAC~50/60Hz |
| Setting range | 0.05 to 0.5 sec, 0.1 to 1 sec, 0.5 to 5 sec, 1 to 10 sec |
| Control output | Time-limit SPDT (1c): 2 |
| Approval | @(CE) @(CULUS) |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH |
| Weight | Approx. 100g |
Tags: AT8PSN-6
