| Operation method | Time setting |
|---|---|
| Output Operation | POWER ON DELAY |
| Time operation | POWER ON START |
| Terminal | 8-pin plug |
| Power supply | 100-240VAC~50/60Hz, 24-240VDC @(=) |
| Setting range | 0.1 to 1 sec, 1 to 10 sec, 0.1 to 1 min, 1 to 10 min, 0.1 to 1 hour |
| Control output | Time-limit SPDT (1c): 1, Instantaneous SPDT (1c): 1 |
| Protection structure | IP40(front panel) |
| Approval | @(CE) @(CULUS) |
| Environment_Ambient temperature | -10 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH |
| Weight | Approx. 122.2g(Approx. 75g) |
Tags: ATE8-41E
