Data sheet?
| Type | Standard type(bolt type) |
|---|
| Sensing distance | 120mm |
|---|
| Min. sensing target | ?0.03mm |
|---|
| Allowable bend radius | R30 |
|---|
| Cable length | 2m |
|---|
| Free cut | Free cut |
|---|
| Environment_Ambient temperature | -40 to 105??/td> |
|---|
| Sensing type | Diffuse reflective type |
|---|
??he sensing distance is a standard for red LED of BF4 Series and 10% of red LED is applied when it is green LED. It is applied to 40% of sensing distance for BF3RX.
??in. sensing target is a value measured opaque material in accurate output status and the sensing distance is different with the rated sensing distance.
??ree cut type's sensing distance can be shortened about max. 20% than the normal according to condition of the cable. [(FC-3) should be used for cutting fiber cable.]
??lass type is for BF5, BF4 Series.
