| Type | communication converter for fiber optic amplifier |
| Display method | 4-digit 7-segment LED |
| Power supply | 12-24VDC @(=) ?10%(ripple P-P: max. 10%) |
| Communication | RS485 communication, Serial communication, SW input |
| Communication speed | 1200, 2400, 4800, 9600, 19200, 38400bps |
| Input | NPN solid-state |
| Application | BFC Series makes for 32 units of fi ber optic amplifi er, BF5 Series, to connect.BFC Series helps for BF5 Series to execute all functions, to setparameters, to monitor real-time data(received light level, output status)via external device(P |
| Protection structure | IP40 |
| Approval | @(CE) |
| Environment_Ambient temperature | -10 to 50?? storage: -20 to 60??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Case: Polybutylene terephthalate, Cover: Polycarbonate |
| Accessories | Connector type wire(?4mm, 3-wire, 2m)(AWG22, core diameter: 0.08mm, number of cores: 60, insulator out diameter: ?1.25mm), Side connector |
| Weight | Approx. 15g |
